Product Description: MAXLIFT MANUAL CHAIN BLOCK (CHAIN HOIST), LCH-01 Series
The MAXLIFT MANUAL CHAIN BLOCK (CHAIN HOIST), LCH-01 series stands as the industry benchmark in heavy-duty lifting solutions. Engineered for maximum efficiency, safety, and reliability, it is the preferred choice for professionals across construction, manufacturing, logistics, and maintenance industries.
Model Range and Versatility:
- Available Models: LCH-01, LCH-02, LCH-03, LCH-05, LCH-10, LCH-15
- Lifting Capacities: From 1 ton up to an impressive 15 tons, providing tailored solutions for both light and heavy lifting requirements.
Key Features & Specifications:
- Lifting Height: Standardized at 3 meters for all models, delivering consistent vertical reach for a range of applications.
- Load Chain: High-strength alloy steel chains with dimensions varying by model—6.3 x 19 mm (LCH-01), 8 x 24 mm (LCH-02), 7.1 x 21 mm (LCH-03), and 9 x 27 mm (LCH-05, LCH-10, LCH-15)—ensuring durability and smooth operation.
- Chain Fall: Engineered with varying chain fall numbers (1 to 6) for optimal load distribution and mechanical advantage.
- Proof Load: Each model undergoes rigorous testing with proof loads up to 150% of the rated capacity (e.g., LCH-10: proof load 12.5 t).
- Effort to Lift Max. Load: Exceptionally low hand effort required—from as little as 330 N to 435 N—enabling safe lifting by a single operator.
- Weight & Portability: Ranges from a lightweight 10 kg for the LCH-01 model to a robust 120 kg for the LCH-15, available in either box or heavy-duty wooden crate packaging for secure transportation and storage.
Expertly Designed for Demanding Environments: MAXLIFT Manual Chain Hoists are crafted for uncompromising performance under the toughest conditions. Each unit is designed for ease of installation and operation, minimal maintenance, and extended service life. Robust construction and precision gearing assure smooth and safe lifting, every time.
Technical Summary Table (Key Models):
| Model | Capacity | Proof Load | Lifting Height | Load Chain | Chain Fall | Effort to Lift | Net Weight | Packaging | |----------|----------|------------|---------------|---------------|------------|----------------|------------|--------------| | LCH-01 | 1 t | 1.5 t | 3 m | 6.3 x 19 mm | 1 | 330 N | 10 kg | Box | | LCH-02 | 2 t | 3 t | 3 m | 8 x 24 mm | 1 | 365 N | 18.8 kg | Box | | LCH-03 | 3 t | 4.5 t | 3 m | 7.1 x 21 mm | 2 | 385 N | 25.6 kg | Box | | LCH-05 | 5 t | 7.5 t | 3 m | 9 x 27 mm | 2 | 435 N | 42.8 kg | Box | | LCH-10 | 10 t | 12.5 t | 3 m | 9 x 27 mm | 4 | 435 N | 79.5 kg | Wooden Crate | | LCH-15 | 15 t | 18.75 t | 3 m | 9 x 27 mm | 6 | 435 N | 120 kg | Wooden Crate |
Keywords: manual chain block, chain hoist, heavy duty, lifting equipment, industrial hoist, MAXLIFT, LCH series, reliable, durable, efficient, high capacity, proof load, load chain, construction hoist, warehousing, material handling.
Choose MAXLIFT—for superior lifting performance and safety. Trust in industry-proven expertise.
